Description
- Selectable power output: Choose 60W, 45W, 35W, or 25W via dip-switch to match each installation perfectly
- Selectable CCT: 3000K (warm), 4000K (neutral), or 5000K (cool white) – adjust on site, no separate stock required
- Lumileds SMD2835 LEDs: Premium-grade diodes delivering up to 150 lumens per watt – 8400 / 6300 / 4900 / 3500 lm depending on power setting
- SOSEN NH-E series driver: Higher-class driver with 0.95 power factor for reliable, efficient operation
- Wide input voltage: AC 100–277V at 50/60Hz suits global and South African grids
- 6kV surge protection: L-N: 6kV / L/N-PE: 6kV defence against lightning and grid spikes
- Multiple beam optics: TYPE II (64×155°), TYPE III (60×155°), TYPE IV (60×150°), 60°, and 90° to suit roads, perimeters, courtyards, and open areas
- Frosted PC cover option: Reduces UGR (Unified Glare Rating) for enhanced visual comfort in pedestrian areas
- IP66 weatherproof rating: Fully dust-tight and protected against powerful water jets – built for any climate
- IK09 impact rating: Vandal- and impact-resistant for public and high-risk installations
- Built-in NEMA socket: Plug-and-play compatibility with photocells, smart controllers, and IoT modules
- Daylight sensor: Available for automatic dusk-to-dawn operation
- 1-10V dimming optional: Compatible with smart lighting and energy-management systems
- Battery backup: Available on request for emergency lighting applications
- Improved heat dissipation: New housing tooling for cooler running temperatures and longer LED life
- External dip-switch: Convenient on-site configuration without opening the fixture
- SUS316 stainless steel screws: Superior corrosion protection for coastal and humid environments
- Premium materials: Aluminium body with polycarbonate cover for durability and optical clarity
- Wide operating temperature: -30°C to 50°C for reliable performance in extreme climates
- 50,000-hour lifespan: L80B20 rated for decades of dependable service
- Fully certified: CE / ENEC / RoHS / ErP2.0 / SAA / IEC / LOA compliant
- 5-year warranty: Long-term reliability guaranteed
- Ideal applications: Public parks, gardens, walkways, plazas, residential estates, parking lots, business parks, and commercial streetscapes
Application-Based Power Guide:
| Setting | Lumens | Best Suited For |
|---|---|---|
| 25W | 3,500 lm | Garden paths, low-traffic walkways, residential entrances |
| 35W | 4,900 lm | Residential estates, courtyards, small parking areas |
| 45W | 6,300 lm | Commercial walkways, plazas, public parks |
| 60W | 8,400 lm | Streetscapes, large parking lots, industrial perimeters |
